Resistance and Continuity Measurements
1. Set the function switch to the "OHM" position.
2. Insert the black test lead banana plug into the negative COM jack and the red test lead banana plug into the
positive jack.
3. For Continuity, press the "DC/AC" key until the " " symbol appears on the display.
4. Touch the test probe tips across the circuit or part under test. It is best to disconnect one side of the part under
test so the rest of the circuit will not interfere with the resistance reading.
5. For Resistance tests, read the resistance on the display.
6. For Continuity tests, If the resistance is < 60 ohms, an audible tone sounds (LCD also shows the actual
resistance).
Capacitance Measurements
1. Set the function switch to the "CAP" position.
2. Insert the black lead into the negative COM jack and the red test lead into the positive CAP jack.
3. Touch the test leads to the capacitor to be tested and read the measured value.
