Extech Instruments MultiTec MT310 User Manual

Input Limit Specifications
Function Maximum Input
V DC or V AC 1000V DC or AC Peak, < 10 seconds
mA DC/AC 400mA DC/AC, fused 250V, 0.5A
A DC/AC 20A DC/AC, < 30 seconds (every 15min); Fused 250V, 20A
Frequency 250V DC or AC peak
Resistance 250V DC or AC peak, <10 seconds
Duty Cycle 250V DC or AC peak
General Specifications
Duty Cycle 0.1% to 99.9%
Diode Test Test voltage of 1.5V (max)
Continuity Check Audible tone if the resistance is less than 60Ω
Input Impedance 10MΩ (VDC and VAC), 100MΩ in the 400mV range
Display 4000 count (3 ¾ digit) LCD, Model MT330 with back lighting
Overrange indication LCD displays "OL"
Polarity Auto positive polarity; Minus (-) sign for negative polarity
Low Battery Indication Battery symbol indicates low battery condition.
Power Supply One 9V battery (NEDA 1604)

Extech Instruments MultiTec MT310 Specifications

General

Brand	Extech Instruments
Model	MultiTec MT310
Category	Multimeter
Language	English
