Meter Description
1. AC adaptor input jack
2. Display
3. Power
ON/OFF
4. Source output adjustment arrow buttons
5. Set
button
6. Unit button (mA or %
)
7. I/O MODE button
8. MEM (memory STEP button)
9. Backlight/ZERO
button
10. Test lead inputs
Display Layout
1. SOURCE mode i
con
2. ZERO function status icon
3.
MEASURE mode
icon
4.
Loop Power icon
5.
Auto Power OFF
active icon
6.
Battery status icon
7. Measure mode value
8. Measure mode units icon
9. Datalogger memory location
10.
Source mode value
11.
Source mode uni
ts icon
3
4
5
6
7
8
10
9
2
1
