Page #8 background imageLoading...
Page #8 background image
8 PRC10-EU-EN-V1.2 01.13
Specifications
General Specifications
Display Dot matrix LCD
Maximum Load 1000 ohms @ 24mA
Meter Power 6 AA batteries or AC adaptor
Auto Power OFF Meter automatically powers off after 10 minutes of inactivity
Current output capability 24mADC at 1000 ohms
Operating Temperature 41ºF to 104ºF (5ºC to 40ºC)
Storage Temperature - 4
o
F to 140
o
F (-20
o
C to 60
o
C)
Operating Humidity Max 80% up to 87ºF (31ºC) decreasing linearly to 50% at 104ºF
(40ºC)
Storage Humidity <80%
Operating Altitude 7000ft (2000meters) maximum
Dimensions 159 x 80 x 44 mm (6.3 x 3.2 x 1.7")
Weight 232g (8.2 oz.) without batteries
Range Specifications
Mode Function Range (Resolution) Accuracy (% of reading)
Current 0 to 50mA (0.01mA) Measure
Percent (%) -25% to +230% (0.1%)
Current 0 to 24mA (0.01mA) Source
Percent (%) -25% to +125% (0.1%)
± (0.01% + 1 digit)
Power Loop Power 24 to 30VDC, <50mA
