SET BUTTON
The SET button is used to manually step through the 5 stored output values.
1.
Select the SOUR
CE mode
2.
Press the SET button and the value stored in memory location 01 will be sourced. “MEM.01”
appears in the di
splay.
3. Each press of the SET button will step through the 5 memory locations.
4. The arrow buttons can be used to adjust the value in each memory location.
STEP/MEM BUTTON
The STEP/MEM button is used to automatically step through the 5 stored output values. The meter
can be set for a single cycle of the stored values or a continuous cycle.
1.
Select the SOUR
CE mode
2.
Press and HOLD the STEP/MEM button. ”STEPSS” (single cycle) and “STEPSC”
(continuous cycle) will alternately appear in the display. Release the button when the
desired mode is displayed.
3. In single cycle mode the meter will source the current displayed in MEM01 for 5 sec
onds.
The meter will then advance to MEM02 for 5 seconds. This will continue through MEM05
and then step down through the memory locations. The cycle will end when MEM01 has
been reached.
4.
In the continuous mode the cycle will continue until manually stopped.
5. Momentarily press the STEP/MEM button to stop the cycle. “END” will briefly appear in the
display.
STORING VALUES INTO MEMORY
The default values stored in the memory locations are:
Memory
Location
mA %
M1
4.00mA 0.0%
M2
8.00mA 25%
M3
12.00mA 50%
M4
16.00mA 75%
M5
20.00mA 100%
To change the values in memor
y:
1. Select the SOURCE mode
2. Press the SET button to select the memory location to be changed.
3. Press the arrow buttons to adjust to the new value
4.
Momentarily press the MEM button to store the value. The memory location icon will
blink
while the value is being stored.
