11 SDL400-en-GB_V1.6 12/14
Specifications
General Specifications
Display Backlit LCD; LCD size: 52 x 38mm (2 x 1.5”)
Status indicators Over-range (----) and low battery
Sensor types Light: Supplied color corrected, domed light intensity sensor (meets
C.I.E.); Temperature: Thermocouple (J or K) temperature probe
Temperature compensation Automatic compensation for thermocouple temperature
measurements
Measurement Units Temperature: °C, °F; Light: LUX, Foot candles
Zero Adjust Light function only. Front panel push-button.
Datalogger Sampling Rate AUTO LOGGING: 1, 2, 5, 10, 30, 60, 120, 300, 600, 1800,
3600 seconds. Note that a one (1) second sampling rate
can cause some data loss on slower computers
MANUAL LOGGING: Set the sampling rate to ‘0’
Memory Card SD memory card: 1GB to 16GB size
Data Hold Freeze the displayed reading
Memory Recall Record and Recall the Maximum and Minimum readings
Display update rate Approx. 1 second.
Data Output RS-232 / USB PC computer interface
Operating Temperature 0 to 50°C (32 to 122°F)
Operating Humidity 85% R.H. max.
Auto Power OFF After 10 minutes of inactivity (can be disabled)
Power Supply Six (6) 1.5 VDC batteries (optional 9V AC adaptor)
Power Consumption Normal operation (backlight & datalogger OFF): approx. 6.5mAdc
With backlight OFF and datalogging ON: approx. 30mAdc
With backlight ON add approx. 16mAdc
Weight 346g (0.76 lbs.) meter only
Dimensions Main instrument: 182 x 73 x 47.5mm (7.1 x 2.9 x 1.9”)
