28GB
CFI EXTEL TOPTEL200- 02/2010 - V1
Transfer capacity: 10 mW, mean capacity per channel, up to 30 m inside and
up to 300 m outside
Power supply: Base station: Primary: 220/230 V, secondary 6VDC/300 mA
(Network adapter) Charging station: Primary: 220/230 V NiMH
Capacity recording: Base station: 0.9/1.4 watts (standby/communication)
Charging station: 0.0-0.6 watts (according to charging intensity)
Service life: Standby: Up to 100 hours
Duration of communication: up to 10 hours (according to charging intensity)
Size (LxwxH): Base station: 130x115x60 mm
Mobile handset: 45x145x25 mm
Weight: Base station: approx. 205 g
Mobile handset: approx. 130 g (batteries included)
Miscellaneous: 30 min of total memory
200 saved numbers
Display of the caller with the list of the last 50 received calls.
OPTIONS
• All Extel electric catches:
WECA 90201, WECA 90301 and WECA 90501.
• All Extel electric locks:
WE 5001/2 bis, WE 5002/2 bis and WE 5004/2 bis
• All Extel mechanisms:
WEAT V , WEAT B et WEAT C.
• BS 691
USERS INFORMATIONS
• Never open the apparatus or the guarantee will be invalidated.
• For return in SAV, protect the screen to prevent scratching.
• Only ever clean with a soft cloth; never use solvents
MAINTENANCE
The warranty is void if the parts are dismantled. Clean the outside only with a soft and dry cloth. Before cleaning,
disconnect and switch off the video surveillance system
CautionDo not use any acid or alcohol based or other similar cleaning product or solvent. You may damage the
appliance and the vapours are explosive and dangerous for your health
Do not use any tool which can be voltage conductor (metallic brush, sharp tool…or other) for cleaning
8
9
10
