Extend EXS-303 - Page 35

35
FIGURE 1-1 SEALER SEAT UNIT
NO.
PART NUMBER
DESCRIPTION
QTY
1
P02-0362100
END GRIPPER UNIT
1
2
P02-0362200
WELDING CLAMP UNIT
1
3
SLIDING TABLE UNIT
1
4
SEPETATOR UNIT
1
5
HEATER PLATE UNIT
1
6
P01-0575800
SEALER SIDE PLATE
1
7
P1104-076004ZZ1
BEARING 6004ZZ-NR(CWB)
1
8
P02-0357900
CLAMP SEAT
1
9
P01-057650A
EXIT ADJUST PLATE
1
10
P1101-0905012AN
SCREW M5x12
10
11
P0311-060001600
MICROSWITCH MQS-216
2
12
P1101-0505008AN
SCREW M5x8
2
13
P1103-0205Z
SPRING WASHER φ5
6
14
P1102-0105AN
NUT M5
4
15
P1202-0011500
SEPERATOR ARM SPRING
1
16
P06-0066400
ARM SPACER
4
17
P1202-0011900
WELDING CLAMP SPRING
2
18
P02-0357300
ARM SHAFT
1
19
HOLDING GRIPPER UNIT
1
20
P1202-0011600
SLIDING TABLE SPRING
1
21
P1101-0505030AN
SCREW M5*30
1
22
P1202-0011800
HOLDING GRIPPER SPRING
1
23
P01-0576400
EXIT BASE PLATE
1
24
P02-0359100
CAM UNIT
1
25
P01-0576800
MICROSWITCH BRACKET
1
26
P01-0576200
COVER SUPPORT
1
27
P0303-020000100
FAN NET FG-08
2
28
P0319-S30304
FAN DC24V
1
29
P01-0576300
SLIDING TABLE HOLDER
1
30
P1109-0205010G
PIN 4*10
1
31
P1101-0405012AN
SCREW M5x12
4
32
P01-0584000
HEATER PLATE COVER
1
