FIGURE 2-1 FEED DRIVE UNIT
NO.
PART NUMBER
DESCRIPTION
QTY
1
P02-0363000
GEAR REDUCER
1
2
SEALER SEAT UNIT
1
3
P06-0066600
ADJUSTA PLATE - TOP
1
4
P1101-0905012AN
SCREW M5x12
5
5
P1116-P0400
O RING
1
6
P0501-0019000
DRIVE MOTOR
1
7
P1103-0206Z
WASHER φ6
6
8
P1101-0506012AN
SCREW M6x12
4
9
P0319-S30303
MAGNETIC REED SWITCH LS-3
1
10
P1101-0303006AZ
SCREW M3x6
2
11
P02-0362500
DRIVEN ROLLER UNIT
1
12
P1106-020000200
MAGNET
2
13
P1101-0203008AZ
SCREW M3X8
2
14
P1103-010412N
WASHER φ4
1
15
P1101-0904008AN
SCREW M4x8
1
16
P1101-0906012AN
SCREW M6x12
1
17
P01-0577300
ROLLER PLATE
1
18
P02-0357700
DRIVING ROLLER
1
19
P1108-010505016G
KEY 5*5*16
1
20
P01-0577100
GUIDE COVER
1
21
P1103-010409N
WASHER φ4
2
22
P1103-0204Z
SPRING WASHER φ4
2
23
P1101-0504010AN
SCREW M4x10
2
24
P1109-0105020B
PIN 5*20
1
25
P1101-0705008AB
SCREW M5x8L
1
26
P06-0066500
STRAP GUIDE
1
27
P1109-0205010G
PIN 4*10
2
28
P1101-0506016AN
SCREW M6x16
2
