FIGURE 8-1 SEPARATING PLATE UNIT
NO.
PART NUMBER
DESCRIPTION
QTY
1
P02-0357600
SEPERATOR ARM
1
2
P01-057560A
SEPERATOR PLATE
1
3
P0311-060000200
MICROSWITCH VX-5-1A2
1
4
P01-0575700
ACTUATOR
1
5
P1104-020635ZZ2
BALL BEARING 635ZZ
1
6
P1103-0205Z
SPRING WASHER φ5
4
7
P1101-0105012AZ
SCREW M5*12
1
8
P1101-0505010AN
SCREW M5x10
2
9
P1101-0904008AN
SCREW M4x8
2
10
P1101-0505045AN
SCREW M5*45
1
11
P1102-0105AN
NUT M5
1
12
P1104-0310101
BUSHING CB1010
2
13
P06-0065300
CUSHION SPACER
2
14
P1101-0303012AZ
SCREW M3*12
2
