Extend EXS-303 - Page 49

49
FIGURE 10-1 BODY FRAME
NO.
PART NUMBER
DESCRIPTION
QTY
1
CABINET COMPONENTS
1
2
P02-0362700
CASTER
2
3
P02-0362800
CASTER WITH BRAKE
2
4
P01-0579400
TRACK
1
5
STRAPPING HEAD UNIT
1
6
P01-0584300
GUIDE ROLLER BRACKET
1
7
P02-0076400
GUIDE ROLLER PIN
1
8
P06-002150A
GUIDE ROLLER
1
9
P01-058000A
ELECTRICAL BOX COVER
1
10
P01-057840A
PANEL COVER
1
11
P01-0580200
REAR TABLE COVER
1
12
P01-057810A
BOX STOPPER
2
13
P1101-1105012AZ
SCREW M5*12
4
14
P1103-010510N
WASHER φ5*10
4
15
P1103-0205Z
SPRING WASHER φ5
6
16
P01-0579900
ELECTRICAL BOX
1
17
P01-0580100
FRONT TABLE COVER
1
18
P1114-01000020B
PLASTIC CAPS
6
19
P01-0585000
ELECTRICAL BOX REAR SUPPORT
1
20
P1101-0905012AN
SCREW M5*12
5
21
P06-002200A
CUSHION
1
22
P01-0588000
SUPPORT PLATE
1
23
P01-0588100
SUPPORT BRACKET
1
24
DISPENSER ASSEM
1
25
P1101-0605010BN
SCREW M5*10
12
26
P1101-0906012AN
SCREW M6*12
10
27
P1101-0506020AN
SCREW M6*20
2
28
P1103-0206Z
SPRING WASHER φ6
4
29
P1103-01061301Z
WASHER M6x13x1t
4
30
P1102-0106AZ
NUT, M6
2
31
P1103-01051201Z
WASHER M6x13x1t
2
32
P1102-0105AZ
NUT, M5
1
