FIGURE 11-1 DISPENSER ASSEM
NO.
PART NUMBER
DESCRIPTION
QTY
1
DISPENSER UNIT
1
2
P01-0579200
DISPENSER SEAT
1
3
P1104-076805ZZ0
BALL BEARING 6805ZZNR
2
4
P02-035940A
BARAKE SUPPORT SHAFT
1
5
P01-0578000
BRAKE ARM
1
6
P01-0584500
BRAKE WASHER
1
7
P02-0359300
ROLLER SHAFT
1
8
P01-0584100
ROLLER BRACKET
1
9
P06-000680B
ROLLER
1
10
P01-0578300
BELT PLATE - FRONT
1
11
P01-0584600
BELT PLATE - REAR
1
12
P01-057820A
BELT FIXER
1
13
P01-058420A
BELT ADJUST PLATE
1
14
P1101-0508030AN
SCREW M8*30
1
15
P1202-0012500
BRAKE SPRING
1
16
P1101-0506045AZ
SCREW M6*45
1
17
P0902-0001400
V-BELT
1
18
P1101-0906012AN
SCREW M6*12
5
19
P1101-0506080AN
SCREW M6*80
1
20
P1105-0120B
C-RING S-20
1
21
P1103-01062102Z
WASHER M6x21x2t
1
22
P1103-0206Z
SPRING WASHER φ6
2
23
P1105-0125B
C-RING S-25
2
24
P1103-0208Z
SPRING WASHER φ8
1
25
P1101-0104020AZ
SCREW M4*20
2
26
P1103-0204Z
SPRING WASHER φ4
2
27
P1102-0104AZ
NUT, M4
2
28
P1102-0108AZ
NUT, M8, 12MM
3
29
P1102-0108BZ
NUT, M8
1
