FIGURE 12-1 DISPENSER UNIT
NO.
PART NUMBER
DESCRIPTION
QTY
1
P06-0058200
DISPENSER
2
2
P06-0058500
EXTENSION CLAW
6
3
P06-0058300
DISPENSER CONNECT
1
4
P06-0058400
BRAKE WHEEL
1
5
P1102-0106AZ
SCREW M6
4
6
P06-0058100
DISPENSER HANDLE
2
7
P1103-0206Z
SPRING WASHER φ6
4
8
P1101-0904018AN
SCREW M4*18
6
9
P1103-01040801Z
WASHER M4*8*1t
6
10
P1102-0104AN
NUT M4
6
11
P1103-010612N
WASHER φ6*12*1t
4
12
P1101-0506016AN
SCREW M6*16
4
13
P02-0313700
DISPENSER SHAFT
1
14
P02-0076300
LOCK PIN
1
15
P1109-030801Z
SNAP PIN 08
1
16
P01-0584400
DISPENSER SPACER
1
17
P1105-0125B
C-RING S-25
1
