INSTALLATION OF THE FILTERS
11
IMPORTANT!
Remember to lubricate the
door gaskets with the
silicone stick supplied,
before installation.
1. Remove locks (2 pcs) and open the
latches (6 pcs).
2. Remove the service door.
3. Take the new filter and place
the loop located at the top of
the filter into the holder.
4. Install the filter and tighten the
bolt.
5. Check that the filters are properly
in their seats.
6. Close the maintenance door by
locking simultaneously the
opposite latches. Install the
locking elements.
