Extra 300LT - Performance; Weight & Center of Gravity; System Description

Section 924
KANNAD AF 406 ELT
Page Date: 22. April 2015 924 - 5
Pilot´s Operating Handbook
EXTRA 300LT
• Switch from position „OFF“ to position „ARM“ or press RESET & TEST on the Remote
Control Panel (ensure that the ELT switch is in position „ARM“).
Close to the end of the self-test a short (3-4 sweeps) 121.5 transmission is made.
• confirm this on the aircraft radio.
• After a few seconds, the test result is displayed with the red visual indicator:
• One long flash indicates that the system is operational and that no error conditions were
found.
• A series of short flashes indicates the test has failed.
Remark: The number of flashes gives an indication of the faulty parameter detected during the self-
test.
sehsalFsehsalF
sehsalF
sehsalFsehsalFgninaeMgninaeM
gninaeM
gninaeMgninaeM
1+3egatloVyrettaBwoL
2+3rewoPFRwoL
3+3)yc
neuqerFytluaF(gnikcoLOCVytluaF
4+3demmargorPnoitacifitnedIoN
If self-test fails, contact the distributor as soon as possible. Unless a waiver is granted, flight should
be cancelled.
924.5 PERFORMANCE
Not affected.
924.6 WEIGHT & CENTER OF GRAVITY
Refer to the equipment list in Section 6 of this Handbook.
924.7 SYSTEM DESCRIPTION
The ELT installation consists of the ELT unit fastened to the fuselage structure aft of the back seat,
an antenna located on the main fuselage cover behind the cockpit, and a remote switch with a red
visual indicator (LED) located on the instrument panel. The remote switch has the positions 'ON',
'ARMED' and 'RESET/TEST'.The switch on the ELT unit has the positions 'ARM', 'OFF' and 'ON'.
