6 - 10 Page Date: 6. April 2010
Section 6
Weight and Balance and Equipment List
Pilot´s Operating Handbook
EXTRA 300LT
EXTRA 300LT S/N:6.6 EQUIPMENT LIST
Mooring (10)
2 Wing Tie Down Rings Extra 83801.002-01-FB 0.05 1.07 O
1 Canopy Lock Extra 83401.001-LK 0.25 1.90 O
Venting and Heating (21)
1 Heater Extra Option 300/LT KBS01 3.70 0.20 O
Electrics (24)
1 Battery Concorde RG-25XC 03617 10.40 0.23 R
1 Avionic Master CB 40A Potter&Brumfield 03618 0.05 1.60 R
1 Alternator 65 Amps Bosch FT0001 4.60 -0.86 R
1 Alternator 55 Amps Bosch 33508 4.20 -0.86 A
1 Alternator 65 Amps Prestolite 33558 4.00 -0.86 A
1 Alternator 60 Amps Plane Power 33552 3.00 -0.86 A
1 Shunt (50A, 50mV) Electronics Intern. FA3008 0.09 1.50 R
1 Volt/Ammeter Electronics Intern. FA3007-PG 0.22 1.62 R
1 External Power Socket
(Piper Type) Cole Hersee 31731 0.29 2.33 O
1 Batt. Charger Plug 12 V Extra 02636 0.02 0.17 O
1 12VDC Power Outlet Sutars 1218 31494 0.03 1.62 O
Socket
Cockpit (25)
1 Safety Belt Assy Hooker (1011230 [3x] & FK0002 or FK0019 3.30 2.12 R
Rear Seat 1113012-1 [1x],
(seat belts w. ratchet, 1H5630-3 [2x]
shoulder harness, 1CS924-D [1x])
crotch strap)
1 Safety Belt Assy Hooker 1011230 [4x] 2.90 1.03 R
Front Seat 1H3030-3 [2x]
(seat belts, 1CS924-D [1x]
shoulder harness,
crotch strap)
1 Safety Belt Assy Hooker (1011230 [3x] & FK0004 or FK0020 3.30 1.03 A
Front Seat 1113012-1 [1x],
(seat belts w. ratchet, 1H3030-3 [2x]
shoulder harness, 1CS924-D [1x])
crotch strap)
Emergency Equipment
1 First Aid Pack Hartmann 33423 0.39 2.70 R
Flight Controls (27)
Electric Trim System Ray Allen 31668 0.40 4.24 R
Fuel System (28)
1 Elec. Fuel Pump Weldon Tool B8120-M 01207 1.10 -0.04 R
QTY ITEM MANUFACTURER MODEL NO PART NO WEIGHT ARM INST. R*
(kg) (m) O*
A*
*) R = Required, O = Optional, A = Alternative
Page Date: 6. November 2012
