Extra 300LT - Instrument Markings

2 - 14 Page Date: 6. April 2010
Pilot´s Operating Handbook
EXTRA 300LT
Section 2
Limitations
2.14.3 INSTRUMENT MARKINGS
AIRSPEED INDICATOR
green arc 65 KIAS (120 km/h) - 160 KIAS (296 km/h)
yellow arc 160 KIAS (296 km/h) - 221 KIAS (409 km/h)
red line 221 KIAS (409 km/h)
OIL PRESSURE INDICATOR
red line 25 psig
yellow arc 25 psig - 55 psig
green arc 55 psig - 95 psig
yellow arc 95 psig - 115 psig
red line 115 psig
OIL TEMPERATURE INDICATOR
yellow arc < 140 °F
green arc 140°F - 210°F
yellow arc 210°F - 245°F
red line 245°F
CYLINDERHEAD TEMPERATURE INDICATOR
yellow arc < 150°F
green arc 150°F - 435°F
yellow arc 435°F - 465°F
red line 465°F
RPM INDICATOR
green arc 700 rpm - 2700 rpm
red line 2700 rpm
G - METER
green arc - 5 g - + 8 g
yellow arc + 8 g - + 10 g
red line + 10 g
FUEL FLOW INDICATOR
green arc 0 gal/h - 35 gal/h
red radial 35 gal/h
