Page Date: 6. April 2010 6 - 11
Section 6
Weight and Balance and Equipment List
Pilot´s Operating Handbook
EXTRA 300LT
1 Elec. Fuel Pump Andair PX580-TC-XT 33551 0.47 -0.04 A
1 Fuel Selector Allen 390144 0.19 0.73 R
+ Fuel Lines in Fuselage Parker/Stratoflex 33315 1.65 0.70 R
1 Fuel Cont. Probe Wing VDO FM4006 0.12 0.89 R
1 Fuel Cont. Probe Wing VDO FM4006 0.12 0.89 O
1 Fuel Cont. Probe
Fuselage Tank VDO 01920 0.20 0.44 R
Landing Gear (32)
2 Main Wheel Tires Goodyear/McCreary 5.00-5/6PR 02323 3.90 0.33 R
2 Tube div. FF0016 3.90 0.33 R
2 Wheel assembly Cleveland 02497 6.40 0.33 R
2 Master Brake Cyl. front Matco FB0001 0.55 0.15 R
2 Master Brake Cyl. rear Matco FB0001 0.55 1.15 R
1 Tail Wheel 6" Assy Special Products
(Soft) Aviation Inc. 32477-VB 1.28 5.23 R
1 Tail Wheel 5" Extra 125/50-75ZL 53201.007-VB 0.90 5.23 A
1 Wheel fairing LH
(CFRP) Extra 5D102.301-01-LV 1.11 0.33 O
1 Wheel fairing RH
(CFRP) Extra 5D102.301-02-LV 1.11 0.33 O
1 Brake Fluid Reservoir ACS 02889 0.20 0.04 R
Lights (33)
1 Strobe/Nav Light (RH) Whelen 32989 0.30 1.35 R
1 Strobe/Nav Light (LH) Whelen 32990 0.30 1.35 R
1 Strobe Power Supply Whelen 33427 0.96 1.41 R
1 Landing Light Xevision 33079 0.50 -0.57 O
1 Landing Light (LED) Whelen 33588 0.17 -0.60 A
Navigation / Flight Instruments / Avionics (34)
1 Accelerometer 3-1/8" Kollsman or Pioneer
or Bendix or Jaeger
or Century AN5745 FI3001 0.40 1.60 R
1 Accelerometer 2-1/4" Kollsman or Pioneer
or Bendix or Jaeger
or Century AN5745 01206 0.30 1.60 A
1 Magnetic Compass SIRS Navigation Ltd 33085 0.13 1.62 R
1 Magnetic Compass Airpath 00189 0.25 1.62 A
1 Airspeed Ind., front United Instr. UI8030 B.891 33424 0.32 0.65 O
1 Airspeed Ind., front United Instr. UI8030 B.900 33875 0.32 0.65 A
(dual scale)
1 Airspeed Ind., front (kts) Mikrotechna Praha LUN 1106.K2B4/LT 34157 0.50 0.65 A
1 Airspeed Ind., front (km/h) Mikrotechna Praha LUN 1106.P2B4/LT 34158 0.50 0.65 A
1 Airspeed Ind., rear United Instr. UI8030 B.891 33424 0.32 1.61 R
QTY ITEM MANUFACTURER MODEL NO PART NO WEIGHT ARM INST. R
(kg) (m) O
A
Page Date: 18. June 2013
