Extra 300LT - Page 84

6 - 12 Page Date: 6. April 2010
Section 6
Weight and Balance and Equipment List
Pilot´s Operating Handbook
EXTRA 300LT
QTY ITEM MANUFACTURER MODEL NO PART NO WEIGHT ARM INST. R
(kg) (m) O
A
1 Airspeed Ind., rear United Instr. UI8030 B.900 33875 0.32 1.61 A
(dual scale)
1 Airspeed Ind., rear (kts) Mikrotechna Praha LUN 1106.K2B4/LT 34157 0.50 1.61 A
1 Airspeed Ind., rear (km/h) Mikrotechna Praha LUN 1106.P2B4/LT 34158 0.50 1.61 A
1 Alternate Static Valve Extra 300/L Option StatLei 0.15 1.60 O
1 Altimeter, front United Instr. UI5934PD-3 A.134 30416 0.39 0.66 O
1 Altimeter, front metric United Instr. UI5934PD-3M A.665 33652 0.39 0.66 A
1 Altimeter, front (km) Winter 4 FGH 10 31393 0.60 0.66 A
1 Altimeter, front (ft) Mikrotechna Praha LUN 1128.10B06 34159 0,59 0.65 A
1 Altimeter, rear United Instr. UI5934PD-3 A.134 30416 0.39 1.62 R
1 Altimeter, rear metric United Instr. UI5934PD-3M A.665 33652 0.39 1.62 A
1 Altimeter, rear (km) Winter 4 FGH 10 31393 0.60 1.62 A
1 Altimeter, front (ft) Mikrotechna Praha LUN 1128.10B06 34159 0,59 1.61 A
1 Vertical Speed Ind. United Instr. UI7030 C.27 01485 0.35 1.62 O
1 Vertical Speed Ind., metric United Instr. UI7030-M C.194 33653 0.35 1.62 A
1 Vertical Speed Ind., metric Winter 5 STVM 15 31564 0.45 1.62 A
1 Vertical Speed Ind., (fpm) Mikrotechna Praha LUN 1144.B0B1 34161 0.40 1.61 A
1 Vertical Speed Ind., (m/s) Mikrotechna Praha LUN 1144.F0B1 34162 0.40 1.61 A
1 Attitude Gyro RC Allen RCA2600-2 (0° tilt) 33027 0.24 1.63 O
(electronic. 2 1/4")
1 Attitude Gyro RC Allen RCA2600-2 (0° tilt) 33881 0.13 1.61 A
(electronic. 2 1/4") 102-0202-01
1 Attitude Gyro RC Allen RCA2600-3 (0° tilt) 33217 0.45 1.63 O
(electronic. 3 1/8")
1 Attitude Gyro RC Allen RCA2600-3 (0° tilt) 33882 0.19 1.61 A
(electronic. 3 1/8") 102-0203-01
1 Slip Indicator RC Allen 444-0010-01 33529 0.03 1.63 A
(on RCA 2600)
1 Stall Sensor Extra 7D106.001-VB 0.07 0.45 R
1 Stall Warn Horn EMAG 01600 0.13 1.60 R
1 Slip/Skid Indicator Rieker 1040 FI0009 0.05 1.60 O
Optional Primary Flight Display (ASPEN)
1 EFD1000 Aspen 910-00001-001 1.32 1.55 O
1 CM Pilot Aspen 920-00004-001 0.04 1.50 O
1 CM Pro Aspen 920-00004-002 0.04 1.50 O
1 RSM w GPS Aspen 910-00003-001 0.91 3.95 O
1 RSM Install. bracket Extra EA-86206.10 0.19 3.95 O
Optional Multi-Function Display (ASPEN)
1 EFD1000 Aspen 910-00001-001 1.32 1.55 O
1 EFD500 Aspen 910-00001-003 1.09 1.55 O
1 CM EFD 1000 MFD Aspen 920-00004-004 0.04 1.50 O
1 CM EFD 500 MFD Aspen 920-00004-005 0.04 1.50 O
Page Date: 18. June 2013
