Page Date: 22. April 2015 6 - 15
Section 6
Weight and Balance and Equipment List
Pilot´s Operating Handbook
EXTRA 300LT
QTY ITEM MANUFACTURER MODEL NO PART NO WEIGHT ARM INST. R
(kg) (m) O
A
Engine Controls (76)
1 RPM Vernier Control ACS Products Co. 00113 0.71 0.82 R
1 Mixture Vernier Control ACS Products Co. 00112 0.65 0.94 R
1 Throttle Control Teleflex Marine 33052 0.56 0.60 R
1 Throttle Control Cable Cablecraft 580-540-501 33589 0.63 0.60 A
Engine Indicating (77)
Conventional engine gauges
1 RPM Indicator digital Horizon P100-230-643-00 02489 0.68 1.60 R
1 Oil Press/Oil Temp Ind. D2-OP130U-
(2 1/4") UMA OT300U-01 33428 0.09 1.62 R
1 Oil Temp. Probe UMA 1B3A 33428 0.08 -0.11 R
1 Oil Press. Sender UMA N1EU150G(-A) or 33428 0.12 0.04 R
T1EU150G(-A)
1 Manifold Pressure/
Fuel Flow Ind. United Instr. UI6331-H.217 33448 0.49 1.60 R
1 Fuel Cont. Ind. Wing Datcon 33412 0.14 1.62 R
1 Fuel Cont. Ind.
Fuselage Tank Datcon 33443 0.14 1.62 R
Optional add on to convent eng. Gauges
1 EGT/CHT Indicator UMA D2-ET1K7K-
CT600J-01 33438 0.07 1.62 O
1 EGT Probe UMA 2BU20 0.06 -0.37 O
1 CHT Probe UMA 2B18 or 2B02 0.05 -0.20 O
Option Integrated Engine Instrument System
1 Engine Instr. Display Electronics Intern. MVP-50P-EX-01 33108 0.86 1.55 O
1 Engine Data Converter Electronics Intern. EDC-33P 33283 1.00 0.42 O
1 Fuel Flow Transducer Electronics Intern. FT-60 33288 0.78 -0.57 O
6 EGT Probes Electronics Intern. P-110 33569 0.26 -0.72 O
6 CHT Probes Electronics Intern. P-100 33568 0.16 -0.72 O
1 Oil Temp Probe Electronics Intern. P-120 33289 0.02 -0.09 O
1 OAT Probe Electronics Intern. P-128 33290 0.02 0.77 O
1 Man. Press. Transducer Electronics Intern. PT-30ABS 33284 0.11 0.25 O
1 Oil Pressure Transducer Electronics Intern. PT-100GA 33286 0.05 0.05 O
1 Fuel Press. Transducer Electronics Intern. PT-30GA 33285 0.05 0.05 O
1 Resistive Fuel Level Mod. Electronics Intern. RFLM-4-12V 33109 0.20 0.31 O
Exhaust (78)
1 Exhaust System "6 in 1" Gomolzig EA300-606000 33891 8.48 -0.39 R
(incl. Silencer)
1 2" inlet/outlet cooling Gomolzig EA300-606009 32153
shroud
1 Exhaust System 6 in 1 Gomolzig EA300-606000 (b) 00661 8.48 -0.39 A
(incl. Silencer)
1 3" inlet/outlet cooling Gomolzig EA300-606024 03248
shroud for heating sys.
