Page Date: 22. April 2015 7 - 7
Section 7
Description and Operation of Aircraft and Systems
Pilot´s Operating Handbook
EXTRA 300LT
Position Item
Fig. 1
1 COM
2 G-meter
3 Volt/Amperemeter
4 Airspeed indicator
5 Magn. direction indicator
6 Altimeter
7 Manifold pressure / fuel flow
8 Trim position indicator
9 RPM Indicator
10 Transponder
11 Magneto selector switch and starter
12 Oil pressure / oil temperature
13 EGT / CHT
14 ELT remote switch
15 Trim switch
16 PTT switch
17 Fuel quantity center tank
18 Fuel quantity wing tank
19 Circuit breaker
20 Switches
Position Item
Fig. 2
1 Alternator warning light incl. press-to-test feature
2 Battery switch (red cap)
3 Alternator switch (red cap)
4 Boost pump switch
5 Strobe lights switch
6 NAV lights switch
7 Avionic switch/circuitbreaker
8 Left pedal adjustment switch
9 Right pedal adjustment switch
10 Landing light switch
11 Stall warning circuit breaker
12 spare
13 Starter circuit breaker
14 Alternator field circuit breaker
15 Boost pump circuit breaker
16 Strobe lights circuit breaker
17 NAV lights circuit breaker
18 Instruments circuit breaker
19 Electric pedal adjustment circuit breaker
20 Electric trim system circuit breaker
21 Landing light circuit breaker
22 COM circuit breaker
23 Transponder circuit breaker
N O T E
This list may be modified by the minimum equipment requirements of individual
certifying authorities!
