29
As far as the air inlet box is concerned, there is the
possibility to connect the air inlet pipe above the sliding
base (see pic.14) or under it (see pic.15) depending on
the needs.
The fumes exhaust box is normally delivered with the
relative covering top.
For the annual cleaning of the stove, we suggest to fix
the equipped flange to a suction pipe in order to make
the cleaning easier. (see pic.15).
NB: All these operations must be carried out by a
specialized technician.
Air inlet box
Air inlet box
Covering top for fumes exhaust box
Cleaning flange
for the fume
exhaust box
Put high temperature silicone on the
flange thread and between flange
and sliding base.
