Extraflame DIVINA User Manual

54
16.4 Falò 1XLP – Falò 1CP – Falò 2CP
Maintenance is necessary to ensure the correct function of your stove over time. Failure to do so
may make the device unsafe.
1. CLEANING THE BURN POT
The burn pot must be cleaned every day. To do so:
• Remove the burn pot form its compartment and
clean the holes using the poker provided (see Fig.1).
• Remove the ash from the burn pot using a vacuum
cleaner.
• Vacuum the ash deposited in the burn pot
compartment.
Fig. 1
2. USING THE SCRAPERS
Cleaning the heat exchangers allows you to maintain a
constant heat yield over time.
This type of maintenance
must be carried out at least once a day. For this purpose,
use the special scrapers located in the upper part of the
stove, moving them up and down several times (see Fig.2).
Fig. 2
3. CLEANING THE ASH PANS
The ash pans (indicated by the arrows in Fig.3) should be
emptied as needed using a vacuum cleaner.
Fig. 3
4. CLEANING THE HEAT EXCHANGER (monthly)
The heat exchangers chamber has
to be cleaned once a
month because the ash residue doesn’t let the stove work
properly. To do this, it is necessary to remove the firewall:
• Remove the brazier from his frame
• Rotate the door latch of 180° like in picture 7.
• Take the cast iron and rotate it down.
Picture 4
