16. STOVE CLEANING
16.1 Ecologica – Maxi Comfort Insert
Maintenance is necessary to ensure the correct operation of your stove over time. Failure to do so
may make the stove unsafe.
1. CLEANING THE BURN POT
The burn pot must be cleaned every day. To do so:
• Remove the burn pot form its compartment and clean
the holes using the poker provided (see Fig.1).
• Remove the ash from the burn pot using a vacuum
cleaner.
• Vacuum the ash deposited in the burn pot
compartment.
Fig. 1
2. USING THE SCRAPERS
Cleaning the heat exchangers allows you to maintain a
constant heat yield over time. This type of maintenance must
be carried out at least once a day. For this purpose
, use the
special scrapers located in the upper part of the stove,
moving them up and down several times (see Fig.2).
Fig. 2
3. CLEANING THE ASH PANS
The ash pans should be emptied as needed, either using a
vacuum cleaner or, for the Ecologica model, by pulling out
the ash drawer at the bottom. To remove the drawer,
proceed as follows:
• Press the bottom door downwards and rotate it
outwards (Fig. 3).
• Turn the handle 90° in order to release the drawer
from the fixed body of the stove (Fig. 4).
• Pull out the ash drawer and empty the ashes.
Work in inverse order to reassemble.
Fig. 3
Fig. 4 Fig. 5
