Extraflame DIVINA User Manual

43
Parameter Display D1
Display D2
Function
Adjustment
buttons
Indication
Button to
confirm
0 Enable/disenable weekly programmer 2 or 3 ON/OFF 5
1 Time of 1
st
switch-on 2 or 3 OFF or from 00:00 to 23:50 5
2 Time of 1
st
switch-off 2 or 3 OFF or from 00:00 to 23:50 5
3 Consents 1
st
switch-on/off for the various days 2 or 3 ON/OFF 1, ON/OFF 2, … ON/OFF 7 5
4 Installer parameter 2 or 3 00 5
5 Time of 2
nd
switch-on 2 or 3 OFF or from 00:00 to 23:50 5
6 Time of 2
nd
switch-off 2 or 3 OFF or from 00:00 to 23:50 5
7 Consents 2
nd
switch-on/off for the various days 2 or 3 ON/OFF 1, ON/OFF 2, … ON/OFF 7 5
8 Time of 3
rd
switch-on 2 or 3 OFF or from 00:00 to 23:50 5
9 Time of 3
rd
switch-off 2 or 3 OFF or from 00:00 to 23:50 5
A Consents 3
rd
switch-on/off for the various days 2 or 3 ON/OFF 1, ON/OFF 2, … ON/OFF 7 1
For example, let’s suppose we want to use the weekly programmer function with the three heating
periods as follows:
1
st
period: from 8.00 to 12.00 every day of the week except Saturday and Sunday
2
nd
period: from 15.00 to 22.00 only Saturday and Sunday
3
rd
period: not used
We can now proceed to setting the weekly programmer.
Parameter 0 (D2 = 0 (blinking) , D1 = on )
Use button 2 or 3 to activate the weekly programmer, setting the value to ON.
Parameter 1 (D2 = 1 (blinking), D1 =Ex. “08.00”)
Press button 2 or 3 to set “8.00”, which corresponds to the switch-on time of the 1
st
period. Press
button 5 to confirm and go to the next parameter.
Press button 4 to go back to the previous one.
Parameter 2 (D2 = 2 (blinking), D1 =Ex. “12.00” )
Press button 2 or 3 to set “12.00”, which corresponds to the switch-off time of the 1
st
period.
Press button 5 to confirm and go to the next parameter.
Press button 4 to go back to the previous one.
Parameter 3 (D2 = 3 (blinking), D1 = “off1” )
Enable the first period for every day of the week except Saturday and Sunday, using buttons 2
and 3 as follows:
a. button 3 – to scroll the days
b. button 2 – to enable/disenable (ON/OFF) the first period for that day.
Example:
Day Initial data Function of button 2 Final data Function of button 3
MONDAY
OFF 1
OFF 1  ON 1 and vice versa
ON 1(enable period) Go to following day
TUESDAY
OFF 2
OFF 2  ON 2 and vice versa
ON 2(enable period) Go to following day
WEDNESDAY
OFF 3
OFF 3  ON 3 and vice versa
ON 3(enable period) Go to following day
THURSDAY
OFF 4
OFF 4  ON 4 and vice versa
ON 4(enable period) Go to following day
FRIDAY
OFF 5
OFF 5  ON 5 and vice versa
ON 5(enable period) Go to following day
SATURDAY
OFF 6
OFF 6  ON 6 and vice versa
OFF 6(disable period) Go to following day
SUNDAY
OFF 7
OFF 7  ON 7 and vice versa
OFF 7(disable period) Go to following day
Press button 5 to confirm and go to the next parameter.
Press button 4 to go back to the previous one.
