Introduction
AP-8533 Access Point Installation Guide 5
AP-8533 Antennas
Dual Band 2.4 GHz / 5 GHz WIFI Antennas - US/Taiwan
An AP-8533 external antenna Access Point supports the following antenna options:
Dual Band 2.4 GHz / 5 GHz Internal Antennas - US/Taiwan
An AP-8533 internal antenna Access Point supports the following dual band antenna:
Single Band 2.4 GHz Bluetooth Antennas - US/Taiwan
An AP-8533 external antenna Access Point supports the following Bluetooth antennas:
Note
Per FCC requirement, the use of the Access Point on UNII-1 of 5GHz band requires
installers to input antenna elevation gain during configuration if the AP placement
is outdoors. This information can be found in the Enterprise Wireless LAN Antenna
Specification Guide located at http://www.extremenetworks.com/support/
documentation/.
Part Number
Antenna
Type
2.4 GHZ
Gain (dBi)
5 GHZ Gain
(dBi)
Elevation
Gain
Impedance
(Ohms)
ML-2452-HPAG4A6-01 Dipole 4 7.3 5.7 50
ML-2452-APAG2A1-01 Dipole 2.7 1.7 N/A 50
ML-2452-HPA6-01 Dipole 5.3 6.1 4.09 50
ML-2452-APA2-01 Dipole 3.17 4.85 N/A 50
ML-2452-PNA5-01R Panel 5.5 6 5.2 50
ML-2452-SEC5M4-N36 Polarized
Panel
6.92 7.23 3.95 50
ML-2452-PTA4M4-036 Patch 5 6.6 N/A 50
Antenna
Type
2.4 GHZ
Gain (dBi)
5 GHZ
Gain (dBi)
Elevation
Gain (dBi)
Mono pole 5.2 6.8 Radio 2: 3.4
Radio 3: 4.1
Part Number Antenna Type
2.4 GHZ Gain
(dBi)
Impedance
(Ohms)
ML-2452-APA2-01 Dipole 3.17 50
ML-2452-HPA6-01 Dipole 5.3 50
ML-2452-PNA7-01R Panel 8 50
ML-2452-PNL3M3-1 Panel 9.7 50
ML-2452-PNL9M3-N36 Panel 11 50
AP-8533 Internal Mono pole 7.7 N/A
