Extreme Networks AP-8533 User Manual

31AP-8533 Access Point Installation Guide
4
AP-8533 Access Point
Specifications
Electrical Characteristics
An AP-8533 Access Point has the following electrical characteristics:
Physical Characteristics
An AP-8533 Access Point has the following physical characteristics:
Operating
Current &
Voltage
48VDC, 0.5A (AUX input voltage)
48VDC PWR-BGA48V45W0WW Power Supply
48VDC, 0.5A (POE)
802.3at AP-PSBIAS-2P3-ATR Power Injector
Dimensions 8.25 in. L x 8.25 in. W x 1.8 in. H
210 mm L x 210 mm W x 46 mm H
Weight 3.0 lbs/1.37 kg
Operating
Temperature
32° F to 122° F/0° C to 50° C*
Storage
Temperature
-40° F to 158° F/-40° C to 70° C
Operating
Humidity
95% RH non-condensing
Operating
Altitude
(maximum)
13,000 ft @ 28C
Storage
Altitude
(maximum)
30,000 ft @ 12C
Electrostatic
Discharge
ESD to ±12KV air and ±8KV contact

Extreme Networks AP-8533 Specifications

General

Brand	Extreme Networks
Model	AP-8533
Category	Access point
Language	English
