Procedure
1. Remove the ceiling tiles.
2. Align the accessory on the ceiling rail in such a way that the accessory metal hinges are almost
parallel to the sides of the ceiling rail.
3. Rotate the accessory clockwise until the metal hinges hook over the edge of the rail and the white
tabs click in place.
Note
There are two white tabs in the back of the accessory that holds on to the ceiling rail in
place. Use your finger to push and unhook one side of the white tab if you want to remove
the accessory from the ceiling rail.
Figure 5: AH-ACC-BKT-AX-TB accessory
Callout Description
1 Metal hinges on the AH-ACC-BKT-AX-TB accessory
2 Mounting holes for wall mounting
3 White tab on the AH-ACC-BKT-AX-TB accessory
Install the Access Point on a 15/16 in. Wide Ceiling Rail
Using AH-ACC-BKT-AX-TB Accessory Indoor Mounting Accessory Installation
20 Wi-Fi 6 (802.11ax) Access Points
