Figure 4: AH-ACC-BKT-AX-SL accessory circular tip
Callout Description
1 AH-ACC-BKT-AX-SL accessory circular tip
5. Press and rotate the access point clockwise until it locks into place on the accessory.
6. Plug the RJ45 connector plug into ETH or ETH0, RJ45 connector receptacle on the access point.
7. When using a AP305C/CX or AP410C access point, attach the Ethernet port cap to the access point
Ethernet port.
For more information about Ethernet cap, refer to Ethernet Cap Accessory Information on page 13.
8. Place the cable cover over the Ethernet cable.
9. Replace the ceiling tiles.
Install the Access Point on a 15/16 in. Wide Ceiling Rail Using AH-ACC-
BKT-AX-TB Accessory
Before You Begin
The following hardware is required for installing the AH-ACC-BKT-AX-TB accessory on a 15/16 in. wide
ceiling rail:
• An indoor access point
• One AH-ACC-BKT-AX-TB accessory
About This Task
The AH-ACC-BKT-AX-TB accessory is shipped with most indoor model access points, and is used for
standard drop ceiling rail installation.
Indoor Mounting Accessory Installation
Install the Access Point on a 15/16 in. Wide Ceiling Rail
Using AH-ACC-BKT-AX-TB Accessory
Wi-Fi 6 (802.11ax) Access Points 19
