Table 352: VX-RPS-1000 Power Specifications (continued)
DC output +54.0 VDC, 18.52 A maximum
Maximum output power 1000 W
Table 353: VX-RPS-1000 Environmental Specifications
Operating temperature 0°C to 45°C (32°F to 113°F)
Storage temperature -40°C to 70°C (-40°F to 158°F)
Operating relative humidity 5% to 90% non-condensing
Table 354: VX-RPS-1000 Connector Pin Functions
Pin Function Pin Function
1 12 V power 9 Power good of RPS
2 12 V power 10 Power supply present
3 12 V power 11 12 V current sharing
4 Ground 12 Ground
5 Ground 13 Spare pin
6 Spare pin 14 -55 V current sharing
7 -55 V power 15 -55 V power return
8 -55 V power 16 -55 V power return
3-Slot Modular Shelves: Technical Specifications
Model STK-RPS-1005CH3-E
The following table lists the specifications for the 3-slot modular shelf (model STK-RPS-1005CH3-E).
The shelf is designed for use with the following equipment:
• STK-RPS-1005PS Redundant Power Supply on page 128 (model STK-RPS-1005PS)
• RPS-150XT Redundant Power Supply on page 125 (model 10932)
• Half-Duplex to Full-Duplex Converter (models 10958 and 10959)
Table 355: Physical Specifications
Length 48.20 cm (18.99 in.)
Depth 35.16 cm (13.85 in.)
Height 5.00 cm (1.97 in.)
Weight 2.39 kg (5.27 lb)
3-Slot Modular Shelves: Technical Specifications Technical Specifications
474 ExtremeSwitching Hardware Installation Guide
