Through the console port, you can make a serial connection between your management system and
the access point.
Note
When you connect to the device using the micro USB Console port, the management
station from which you connect to the device must have a VT100 emulation program, such
as Tera Term Pro (a free terminal emulator) or Hilgraeve HyperTerminal (provided with
Windows operating systems from XP forward).
• One reset button
• One Kensington lock
Tip
The best practice is to use Kensington locks for locking the device.
Temperature Specifications
• Operating temperature: 0 °C to +50 °C (+32 °F to +122 °F)
• Storage temperature: -40 °C to +70 °C (-40 °F to +158 °F)
• Relative humidity: 0% to 95% non-condensing
Power Specifications
IEEE 802.3at PoE Power
For detailed specifications, refer to the AP4000 Data Sheet.
Power Profile
• Power draw:
◦ Typical: 13.0 W; Max: 14.5 W (without USB)
◦ Typical: 15.8 W; Max: 17.3 W (with USB)
• 802.3at PoE capable
• Gigabit Ethernet port (RJ45 power input pins: Wires 4,5,7,8 or 1,2,3,6)
Table 4: AP4000 power profile for 802.3af and 802.3at
AP4000 802.3af 802.3at
Radio 0 (2.4G) 2×2 (16 dBm) 2×2 (19 dBm)
Radio 1 (5G) 2×2 (16 dBm) 2×2 (18 dBm)
Radio 2 (6G) 2×2 (16 dBm) 2×2 (18 dBm)
BLE On On
USB O On
Temperature Specifications AP4000 Access Point Overview
10 ExtremeWireless™ Indoor Access Point AP4000
