Figure 6: AH-ACC-BKT-AX-TB accessory
Callout Description
1 Metal hinges on the AH-ACC-BKT-AX-TB accessory
2 Mounting holes for wall mounting
3 White tab on the AH-ACC-BKT-AX-TB accessory
5. Attach the Ethernet port cap to the access point Ethernet port.
For more information about Ethernet cap, refer to Ethernet Cap Accessory Information on the WiFi
6 802.11ax Access Points Accessories Guide.
Install the Access Point on a Standard Ceiling Rail
Install the Access Point
16 ExtremeWireless™ AP410C Access Point
