Extreme Networks ExtremeWireless AP410C User Manual

9. Place the cable cover over the Ethernet cable.
10. Replace the ceiling tiles.
Non-Standard Ceiling Grid or Wall Installation
Details about non-standard ceiling grid or wall installation using optional bracket and accessory.
Note
For all non-standard ceiling grid installation or wall installation instructions, refer to the Wi-Fi
6 802.11ax Access Points Accessories Guide.
Non-Standard Ceiling Grid or Wall Installation Install the Access Point
18 ExtremeWireless™ AP410C Access Point

Extreme Networks ExtremeWireless AP410C Specifications

General

MIMO type	Multi User MIMO
Modulation	256-QAM, 1024-QAM, COFDM, DSSS, OFDM
Number of users	1024 user(s)
Bluetooth version	5.0
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
Maximum data transfer rate	- Mbit/s
Trusted Platform Module (TPM)	Yes
Maximum data transfer rate (5 GHz)	4800 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Security algorithms	WMM, WPA, WPA2, WPA3
Number of SSID supported	16
Placement	Ceiling, Wall
Certification	IEC 60950-1, EN 60950-1, UL 60950-1, CSA 22.2 No.60950-1-03 AS/NZS 60950.1, RoHS Directive 2011/65/EU
Product color	White
Cable lock slot type	Kensington
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
USB connector type	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Antenna type	Internal
Routing protocols	BGP

Weight and Dimensions

Width	205 mm
Height	37 mm
