Summit Family Switches Hardware Installation Guide
364
Summit X440 Series Switches
The Summit X440 series includes the following switches:
● Summit X440-24t switch
● Summit X440-24p switch
Table 67: Summit X440 Series Switch Technical Specifications
Physical Dimensions
Summit X440-24t switch
Summit X440-24p switch
Height: 1.73 inches (4.4 cm)
Width: 17.4 inches (44.1 cm)
Depth: 10.0 inches (43.2 cm)
Weight
Summit X440-24t switch 12 lb (5.45 kg)
Summit X440-24p switch 14.9 lb (6.8 kg)
Packaged Dimensions
Summit X440-24t switch
Summit X440-24p switch
Height: 6.5 inches (16.5 cm)
Width: 23.4 inches (59.3 cm)
Depth: 26.2 inches (66.5 cm)
Packaged Weight
Summit X440-24t switch 23.6 lb (10.7 kg)
Summit X440-24p switch 23.8 lb (10.8 kg)
Fan Speed
Minimum speed 2500 RPM
Maximum speed 15900 RPM
Power: Summit X440-24t
Nominal input ratings 100 to 240 V , 50/60 Hz, 0.75 A
Input current 0.35 A @ 110 V (low-line)
0.23 A @ 220 V (high-line)
Heat dissipation 38 W, 130 BTU/hr
Power consumption 38 W, 130 BTU/hr
Power: Summit X440-24p
Nominal input ratings 100 to 240 V , 50/60 Hz, 6.0 A
Input current 3.7 A @ 110 V (low-line)
2.3 A @ 220 V (high-line)
Heat dissipation 120 W, 410 BTU/hr
Power consumption 490 W, 1672 BTU/hr
Safety Standards
North American Safety of ITE UL 60950-1 2nd Ed., Listed Device (US)
CSA 22.2 #60950-1-03 2nd Ed.(Canada)
Complies with FCC 21CFR 1040.10 (US Laser Safety)
CDRH Letter of Approval (US FDA Approval)
European Safety of ITE EN 60950-1:2007 2nd Ed.
EN 60825-1+A2:2001 (Lasers Safety)
TUV-R GS Mark by German Notified Body
2006/95/EC Low Voltage Directive
