Installing Summit Family Switches
Summit Family Switches Hardware Installation Guide
246
Connecting Equipment to the Console Port
Connection to the console port is used for direct local management. The console port settings are:
● Baud rate—9600
● Data bits—8
● Stop bit—1
● Parity—None
● Flow control—XON/XOFF
The terminal or PC with terminal-emulation software that you connect to an Extreme Networks switch
must be configured with these settings. This procedure is described in the documentation supplied with
the terminal.
Appropriate cables are available from your local supplier, or you can make your own. To ensure the
electromagnetic compatibility of the unit, use only shielded serial cables. For connector pinouts
associated with the console port, see “Console Connector Pinouts” on page 419.
Logging In for the First Time
After your switch has completed all power on self-tests, it is operational. You can log in and configure
an IP address for the default VLAN (named default).
The management port is part of the management VLAN by default.
To manually configure the IP settings:
1 Connect a terminal or PC with terminal-emulation software to the console port on the Summit
switch.
2 At the terminal, press [Return] one or more times until you see the login prompt.
3 At the login prompt, enter the default user name admin to log on with administrator privileges. For
example:
login: admin
Administrator capabilities allow you to access all switch functions.
4 The system will ask a series of questions about the default management settings, which allow all
forms of management access for convenience in setting the initial configuration. Answer each
question based on the level of security needed for the particular management access type.
For more information about logging in to the switch and configuring switch management access, see the
ExtremeXOS Concepts Guide.
5 At the password prompt, press [Return].
The default user name admin has no password assigned to it. When you have successfully logged on
to the system, the command line prompt displays the system name (for example, SummitX450>) in
its prompt.
