qos map dscp-egress-translation {0–63 | {be | af11 | af12 | af13 | af21 |
af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 |
cs4 | cs5 | cs6 | cs7 | ef | va}} 0–1 to {0-63 | {be | af11 | af12 | af13
| af21 | af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2
| cs3 | cs4 | cs5 | cs6 | cs7 | ef | va}}
Parameters
Name Description
0–7
Cos level
0-63
Dscp level
be
Default PHB(DSCP 0) for best eort trac
af11–13
Assured Forwarding PHB 11–13(DSCP 10,12,14)
af22–23
Assured Forwarding PHB 22–23(DSCP 20,22)
af31–33
Assured Forwarding PHB 31–33(DSCP 26,28,30)
af41–43
Assured Forwarding PHB 41–43(DSCP 34,36,38)
cs1–7
Class Selector PHB CS1–7 precedence 1–7(DSCP 8*(cs value))
ef
Expedited Forwarding PHB(DSCP 46)
va
Voice Admit PHB(DSCP 44)
0–1
Specific drop precedence level
qos map dscp-ingress-translation
Description
Configure dscp ingress-translation
Syntax
qos map dscp-ingress-translation {0–63 | {be | af11 | af12 | af13 | af21
| af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 |
cs4 | cs5 | cs6 | cs7 | ef | va}} to {0-63 | {be | af11 | af12 | af13 |
af21 | af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 |
cs3 | cs4 | cs5 | cs6 | cs7 | ef | va}}
Parameters
Name
Description
0–7
CoS level
0-63
DSCP level
be
Default PHB(DSCP 0) for best eort trac
af11–13
Assured Forwarding PHB 11–13(DSCP 10,12,14)
af22–23
Assured Forwarding PHB 22–23(DSCP 20,22)
ISW Commands
ISW Series Managed Industrial Ethernet Switch Command Reference Guide 109
