Extron electronics XTP II CrossPoint 1600 User Manual

SIS Command and Response Table for Input-Board-Specific Commands (continued)
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Inputs on XTP CP 4i VGA (Analog Video) Boards
Input video format
Set format
X^
*
X3)
\ Ityp
X^
*
X3)
*
X3!]
Set input
X^
to
X3)
video format. The
board reports the detected video
format,
X3!
, in the response.
Example:
1*0\
Ityp01*0*5
]
Set input 1 to auto. The board reports
RGB video.
View format
X^
\
X3)
*
X3!]
View set (
X3)
) and detected (
X3!
) video
format of input
X^
.
Image reset
Execute an image reset
E
I
X^
*2AADJ
}
AadjI
X^
*2
]
Reset input signal timing to Extron
default for input
X^
.
Color
NOTE: Color adjustments are available for RGBcvS (SCART), interlaced component video (YUVi), S-video, and NTSC composite video
inputs.
Set a specific color value
E
I
X^
*
X3@
COLR
}
ColrI
X^
*
X3@]
Specify the color adjustment.
Increment color value
E
I
X^
+COLR
}
ColrI
X^
*
X3@]
Increase the color setting by one.
Decrement color value
E
I
X^
–COLR
}
ColrI
X^
*
X3@]
Decrease the color setting by one.
View the color value
E
I
X^
COLR
} X3@]
Show the color setting.
Tint
NOTE: Tint adjustments are available for NTSC S-video, and NTSC composite video inputs.
Set a specific tint value
E
I
X^
*
X3@
TINT
}
TintI
X^
*
X3@]
Specify the tint adjustment.
Increment tint value
E
I
X^
+TINT
}
TintI
X^
*
X3@]
Increase the tint setting by one.
Decrement tint value
E
I
X^
–TINT
}
TintI
X^
*
X3@]
Decrease the tint setting by one.
View the tint value
E
I
X^
TINT
} X3@]
Show the tint setting.
Brightness
NOTE: Brightness adjustments are available for RGBcvS (SCART), interlaced component video (YUVi), S-video, and NTSC composite
video inputs.
Set a specific brightness value
E
I
X^
*
X3@
BRIT
}
BritI
X^
*
X3@]
Specify the brightness adjustment.
Increment brightness value
E
I
X^
+BRIT
}
BritI
X^
*
X3@]
Increase the brightness setting by one.
Decrement brightness value
E
I
X^
–BRIT
}
BritI
X^
*
X3@]
Decrease the brightness setting by one.
View the brightness value
E
I
X^
BRIT
} X3@]
Show the brightness setting.
Contrast
NOTE: Contrast adjustments are available for RGBcvS (SCART), interlaced component video (YUVi), S-video, and NTSC composite
video inputs.
Set a specific contrast value
E
I
X^
*
X3@
CONT
}
ContI
X^
*
X3@]
Specify the contrast adjustment.
Increment contrast value
E
I
X^
+CONT
}
ContI
X^
*
X3@]
Increase the contrast setting by one.
Decrement contrast value
E
I
X^
–CONT
}
ContI
X^
*
X3@]
Decrease the contrast setting by one.
View the contrast value
E
I
X^
CONT
} X3@]
Show the contrast setting.
NOTE: X3) = Input video source 0 = Auto (default)
1 = Video 3 = RGBcvS (SCART) 5 = RGB
2 = S-video 4 = YUV interlace 6 = YUV
X3! = Detected video format 0 = no signal detected
1 = Video 3 = RGBcvS (SCART) 5 = RGB
2 = S-video 4 = YUV interlace 6 = YUV
X^ = Input number (for other than tie) 01 – 16, 32, or 64
X3@ = Picture adjustments 000 through 255 (128 = default)
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 93
