Extron electronics XTP II CrossPoint 1600 User Manual

SIS Command and Response Table for Input-Board-Specific Commands (continued)
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Inputs on XTP CP 4i VGA (Analog Video) Boards (continued)
Pixel phase
NOTE: Pixel phase adjustments are available for RGBHV and non-interlaced component video (YUVp) video inputs.
Set a specific pixel sampling phase
E
I
X^
*
X3@
PHAS
}
PhasI
X^
*
X3@]
Specify the pixel sampling phase.
Increment sampling value
E
I
X^
+PHAS
}
PhasI
X^
*
X3@]
Increase the phase value.
Decrement sampling value
E
I
X^
–PHAS
}
PhasI
X^
*
X3@]
Decrease the phase value.
View the sampling value
E
I
X^
PHAS
} X3@]
Show the pixel sampling phase.
Horizontal shift
Specify a value
E
I
X^
*
X3#
HCTR
}
HctrI
X^
*
X3#]
Set the horizontal location of first active
pixel in input
X^
.
Increment value
E
I
X^
–HCTR
}
HctrI
X^
*
X3#]
Increase the value by one pixel (shift the
image to the right).
Decrement value
E
I
X^
+HCTR
}
HctrI
X^
*
X3#]
Decrease the value by one pixel (shift
the image to the left).
View
E
I
X^
HCTR
} X3#]
Show the horizontal location of first
active pixel in input
X^
.
Vertical shift
Specify a value
E
I
X^
*
X3#
VCTR
}
VctrI
X^
*
X3#]
Set the vertical location of first active
pixel in input
X^
.
Increment value
E
I
X^
+VCTR
}
VctrI
X^
*
X3#]
Increase the value by one line (shift up).
Decrement value
E
I
X^
–VCTR
}
VctrI
X^
*
X3#]
Decrease the value by one line (shift
down).
View
E
I
X^
VCTR
} X3#]
Show the vertical location of first active
pixel in input
X^
.
Save and recall analog input presets
NOTES:
• Analog input presets are available for analog (RGB, YUVp, YUVi, S-video, composite) video input signals on an XTP CP 4i VGA
universal analog input board only.
• Analog input presets save a set of analog variables, such as: horizontal and vertical shift, pixel phase, color and tint, brightness
and contrast, and input type.
Save an analog input preset
X^
*1*
X3$
, Spr
X^
*1*
X3$]
Command character is a comma.
Recall an analog input preset
X^
*1*
X3$
. Rpr
X^
*1*
X3$]
Command character is a period.
NOTE: X^ = Input number (for other than tie) 01 – 16, 32, or 64
X3# = Shift 00000 through 65535
X3$ = Analog input preset 1 through 8
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 94
