SIS Command and Response Table for Input-Endpoint-Specific Commands (continued)
Command Function
SIS Command
(Host to Unit to Endpoint)
Response
(Endpoint to Unit to Host)
Additional Description
XTP T USW 103 switcher specific commands
Input video format (available for endpoint input 1 only)
Set format
X^
*
X3)
\ Ityp
X^
*
X3)
*
X3!]
Set input
X^
to
X3)
video format. The
board reports the detected video
format,
X3!
, in the response.
Example:
1*0\
Ityp01*0*5
]
Set input 1 to auto. The board reports
RGB video.
View format
X^
\
X3)
*
X3!]
View set (
X3)
) and detected (
X3!
) video
format of input
X^
.
Image reset (available for endpoint input 1 only)
Execute an image reset
X^
A Aadj
X^]
Reset input signal timing to Extron
default for input
X^
.
Pixel phase
NOTE: Pixel phase adjustments are available for RGBHV and non-interlaced component video (YUVp) video inputs.
Set a specific pixel sampling phase
E
I
X^
*
X3@
PHAS
}
PhasI
X^
*
X3@]
Specify the pixel sampling phase.
Increment sampling value
E
I
X^
+PHAS
}
PhasI
X^
*
X3@]
Increase the phase value.
Decrement sampling value
E
I
X^
–PHAS
}
PhasI
X^
*
X3@]
Decrease the phase value.
View the sampling value
E
I
X^
PHAS
} X3@]
Show the pixel sampling phase.
Horizontal shift (available for endpoint input 1 only)
Specify a value
E
I
X^
*
X3#
HCTR
}
HctrI
X^
*
X3#]
Set the horizontal location of first active
pixel in input
X^
.
Increment value
E
I
X^
–HCTR
}
HctrI
X^
*
X3#]
Increase the value by one pixel (shift the
image to the right).
Decrement value
E
I
X^
+HCTR
}
HctrI
X^
*
X3#]
Decrease the value by one pixel (shift
the image to the left).
View
E
I
X^
HCTR
} X3#]
Show the horizontal location of first
active pixel in input
X^
.
Vertical shift (available for endpoint input 1 only)
Specify a value
E
I
X^
*
X3#
VCTR
}
VctrI
X^
*
X3#]
Set the vertical location of first active
pixel in input
X^
.
Increment value
E
I
X^
+VCTR
}
VctrI
X^
*
X3#]
Increase the value by one line (shift up).
Decrement value
E
I
X^
–VCTR
}
VctrI
X^
*
X3#]
Decrease the value by one line (shift
down).
View
E
I
X^
VCTR
} X3#]
Show the vertical location of first active
pixel in input
X^
.
Save and recall analog input presets (available for endpoint input 1 only)
NOTES:
• Analog input presets are available for analog (RGB, YUVp, YUVi, S-video, composite) video input signals on an XTP CP 4i VGA
universal analog input board only.
• Analog input presets save a set of analog variables, such as: horizontal and vertical shift, pixel phase, color and tint, brightness
and contrast, and input type.
Save an analog input preset
X^
*1*
X3$
, Spr
X^
*1*
X3$]
Command character is a comma.
Recall an analog input preset
X^
*1*
X3$
. Rpr
X^
*1*
X3$]
Command character is a period.
NOTE: X^ = Input number (for other than tie) 01 – 16, 32, or 64
X3) = Input video source 0 = Auto (default)
1 = Video 3 = RGBcvS (SCART) 5 = RGB
2 = S-video 4 = YUV interlace 6 = YUV
X3! = Detected video format 0 = no signal detected
1 = Video 3 = RGBcvS (SCART) 5 = RGB
2 = S-video 4 = YUV interlace 6 = YUV
X3@ = Picture adjustments 000 through 255 (128 = default)
X3# = Shift 00000 through 65535
X3$ = Analog input preset 1 through 8
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 97
