extronics iTAG XB BLE - Page 2

2
Contents
Tag Operation ..................................................................................................... 3
1.1 Device States: ............................................................................................... 3
1.2 Wake up procedure ....................................................................................... 3
1.3 Power on self-test mode ................................................................................ 3
1.4 LED Status Indicator ...................................................................................... 4
Supported Beacon Profiles .................................................................................. 5
Motion detection Engine: ..................................................................................... 9
3.1 Coarse Filter .................................................................................................. 9
Device Configuration ......................................................................................... 11
Device MAC address ......................................................................................... 13
PC Tool - SenseBLE Control ............................................................................. 14
Open SenseBLE Control ....................................................................................... 14
6.1 Read existing Device Configuration ............................................................. 15
6.2 Save new Configuration to Device ............................................................... 16
6.3 Write new Configuration to Device .............................................................. 18
Battery Information ............................................................................................ 19
7.1 Battery Types: ............................................................................................. 19
7.2 Battery Replacement – iTAG XB10 - Sense Lite V2 .................................... 20
7.2.1 Remove the battery ............................................................................... 21
7.2.2 Install the battery ................................................................................... 22
7.3 Battery Replacement – iTAGXB40 - Sense Ultra ........................................ 25
7.3.1 Remove the Batteries ........................................................................... 26
7.3.2 Install the Batteries ............................................................................... 27
Care and Maintenance ...................................................................................... 29
Recycling and Disposal ..................................................................................... 29
APPENDIX A - iTAGXB40-B parameters for iTAG X-Range .................................... 30
