CE DECLARATION OF CONFORMITY
Manufacturer: FAAC S.p.A.
Address: Via Benini, 1 - 40069 - Zola Predosa - Bologna - ITALY
Declares that: control unit 550 ITT
• conforms to the essential safety requirements of the following EEC directives:
73/23/EEC and subsequent amendment 93/68/EEC.
89/336/EEC and subsequent amendment 92/31/EEC and 93/68/EEC
Additional information:
This product underwent a test in a typical, uniform configuration (all products manufactured by FAAC S.p.A.).
Bologna, 01-08-2006
The Managing Director
A. Bassi
Notes on reading the instruction
Read this installation manual to the full before you begin installing the product.
The symbol indicates notes that are important for the safety of persons and for the good condition of the
automated system
The symbol draws your attention to the notes on the characteristics and operation of the product.
INDEX
2. HARDWARE SPECIFICATIONS pag.9
3. BOARD LAY-OUT pag.9
1. OPERATING PARAMETERS pag.9
4. BOARD COMPONENTS pag.10
5. ELECTRICAL CONNECTIONS pag.10
5.1. DESCRIPTION OF CONNECTIONS pag.10
6. SIGNALLING LEDs pag.11
7. PROGRAMMING pag.12
7.1. BASIC PROGRAMMING pag.12
7.2. ADVANCED PROGRAMMING pag.12
8. ROTATION DIRECTION CHECK pag.14
9. ADJUSTMENT OF ELECTRONIC CLUTCH (ANTI-CRUSHING) pag.14
10. ENCODER OPERATION pag.14
