3.6. SIGNALLING LEDs
6 LEDs are fitted on the card, indicating status of terminal board
inputs:
LED LIGHTED
= contact closed
LED OFF
= contact open
4. PROGRAMMING
To program operation of automation, use the microswitches as
shown below.
1 2 3 4 5 6 7
Operation of warning light
Gate status
SW6
Closed Opening/Open Closing
ON
OFF
Light
Flashing
Light
Off
Steady light
Pre-flashing (2)
SW7
Yes ON
No OFF
Logic SW1 SW2 SW3
E1 ON ON ON
B OFF ON ON
S2 ON OFF ON
E2 OFF OFF ON
A1 ON ON OFF
C OFF ON OFF
S1 ON OFF OFF
A2 OFF OFF OFF
Pause time (sec) (1)
Logic
A1-A2-S2 S1 SW4 SW5
515ONON
10 30 O FF ON
30 60 O N O FF
120 180 OFF OFF
ON
OFF
(1) Pause times include pre-flashing if any
(2) Pre-flashing begins 5” before every movement.
! You must press the RESET push-button after every program-
ming job.
4.1. FUNCTION LOGICS
The following are available:
A1/A2 = “Automatic” S1/S2 = “Safety”
E1/E2/B = “Semi-automatic” C = “Dead man”
Operation of automation in the different logics is indicated in
Tables 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10.
4.2. PAUSE TIME
Pause time is waiting time in open position before re-closing
when an automatic logic was selected.
Pause times include pre-flashing if any
4.3. OPERATION OF WARNING LIGHT
Used to change the appearance of the warning light at closing
by making it flash.
4.4. PRE-FLASHING
Flashlight pre-flashing time of 5 sec before any movement can
be selected. This warns anyone near the gate that it is about to
move.
5. FAULT CONDITIONS
The following conditions cause certain effects to normal opera-
tion of automation:
햲 microprocessor error
햳 safety electronic timing tripped (operation is interrupted if
continuous work time exceeds 255 sec. ).
햴 limit sensors disconnected (or both engaged)
• Conditions 햲 and 햳 cause automation to stop and nothing
more.
• Condition 햴 causes an alarm situation disabling any activ-
ity:
• Normal operation can be restored only after eliminating the
alarm cause and pressing the RESET push-button (or turning
off power supply momentarily).
• To have this condition signalled, the warning light must be
connected: the alarm is signalled by very rapidly flashing light
(0.25 sec).
NB.: The status of the LEDs while the gate is closed at rest are
shown in bold.
DELDETHGILFFO
ANEPO
evitcadnammoC
evitcanidnammoC
BNEPO
evitcadnammoC
evitcanidnammoC
POTS
evitcanidnammoC
evitcadnammoC
WSF
gnitarepotonsecivedytefaS
gnitareposecivedytefaS
CCF
eerfrosnestimilgnisolC
degagnerosnestimilgnisolC
ACF
eerfrosnestimilgninepO
degagnerosnestimilgninepO
Tab. 2 - STATUS OF LEDS
