E721 2 532014 - Rev.E
E721
Fig. 1
/
SAFE
/ SAFE
ENGLISH
1 WARNINGS
Before attempting any work on the control board (connections, maintenance), always turn off power.
Install, upstream of the system, a differential thermal breaker with adequate tripping threshold.
Connect the earth lead to the appropriate terminal.
Always separate power cables from control and safety cables
(push-button, receiver, photocells, etc.). To avoid any electric
noise, use separate sheaths or a shielded cable (with earthed
shield).
2 LAYOUT AND COMPONENTS
SENSOR
LIMIT SWITCH
