Definitions

Definitions of Front View parts

• Passive Infrared Sensor: Used to detect the moving infra-

red heat. i.e. people

• Microphone: Can record sound while video recording

• Infrared LED: Invisible light for night time capture

• Status display: Displays the settings and camera status

• Camera Lens: Used to capture the image/video

• EJECT Button: Pressing this button releases the battery

tray to gain access to the batteries to install or replace

(Batteries Not Supplied)

• Slide Switch: To select the different camera modes,

changing the camera status, TEST, OFF, Preset A, B or CAM

• Test / Batt Low Indicator: Indicates the PIR detection

coverage when camera is switched to TEST or indicate the

battery is low

• USB Port: Used to connect the camera to PC by the

provided USB cable for captured image/video download

• [▲]Up and [▼] Down Button: To change the mode and

adjust the setting value when camera is switched to TEST

• SD Card Slot: Used to install the SD memory card, the

camera supports SD memory card up to 32GB

• [M] Menu Button: Used for entering the camera’s menus

or press and hold 2 seconds for exit
