Facnor LS PLUS - Box Content

Facnor - Installation manual rev 2012 – LS+/LX+/RX+ reefing and furling systems
2.1 BOX CONTENT
2.1.1 Standard components
Chart No1
Maximum forestay length 8M30 10M40 12M40 14M40 16M40 18M40 20M40 22M40
A = Number of bushings necessary* 7 8 9 10 11 12 13 14
B = Number of screws necessary * 16 20 24 28 32 36 40 44
* NOTE : the quantity contained in the bag is superior to the number of screws or bushings required
2.1.2 Optional extras (not included in standard kit)
 Internal turnbuckle option
 Turnbuckle kit (for installation see p. 24)
 Furling line kit (for installation see p. 26)
Chart No.2
Length-rope Ø 20M x Ø 06MM 24M x Ø 08MM 24M x Ø 10MM
Quantity C 44 4 4
Furl. system model LS/LX 60-100 RX70-100 LS/LX 130-180 RX130-200 LS/LX 200-290 RX260-300
19
Drum fitted with internal turnbuckle option
2 x
L
S
/RX/RS models
A x
B x
LX models
See chart No1
See chart No1
2 x
1 x
2 x
LX/RX/RS models
2 x
LX/RX models
2 x 2 x 2 x 1 x
C x
