Facnor LS - Assembly Drawing; Package Inventory and Tube Content

Facnor - LS / LX / RS / RX reefin
g
and furlin
g
systems - Installation manual
1- ASSEMBLY DRAWING
halyard deflector
top cap
top foil section
halyard swivel
2-meter-standard section
connector
black bushing (split into 2 half bushings)
sail feeder
drum
Lower drum fixing : 2 possible assemblies (see p.24)
pin with nylon bushes
or
turnbuckle kit (stainless steel curved plates, optional)
2- PACKAGE INVENTORY
The Facnor headsail reefing system comprises:
18
3
7
6
2
1
1
2
3
4
5
6
7
8
9
4
5
10
11
8
9
10
11
+
