Facom 714A - GENERAL SPECIFICATION

21
The batteries in the battery compartment are low and should be replaced immediately.
Warning:Toavoidfalsereadings,whichcouldleadtopossibleelectricshockorpersonalinjury,replacethebatteries
as soon as this lowbattery indicator appears.
Battery internal resistance test indicator. It appears when battery internal resistance test is enabled.
Battery internal resistance test is in Fixed Time Test mode.
Battery internal resistance test is locked so that you can perform the test continuously as long as as you like.
Number of cylinders of the engine to be tested
18. Units on the LCD
  VoltageunitmV:Millivolt;V:Volt1V=10
3
mV
  CurrentunitIA:Microamp;mA:Milliamp;A:Ampere1A=103mA=106IA
  Resistanceunitm:Milliohm;:Ohm;k:KilohmM:Megohm;1M=103k=106=109m
  FrequencyunitHz:Hertz;kHz:Kilohertz;MHz:Megahertz1MHz=103kHz=106Hz
  RotationspeedunitRPM:Revolutionsperminute
  Temperatureunit°C:Celsiusdegree;°F:Fahrenheitdegree
Unit of dwell angle °: Degree
Unit of duty cycle % : Percent
18. Analog Bar Graph
The length of its lit segments is proportional to the present reading on the LCD. The bar graph is like the needle on an analog
meter. It has an overload indicator ( ) on its right and a negative polarity indicator ( ) on its left. Because the bar graph
updates10timesfasterthanthedigitaldisplay,thebargraphisusefulformakingpeakandnulladjustmentsandforobserving
rapidly changing inputs. The number of lit segments indicates the measured value and is relative to the full-scale value of the
selectedrange.Inthe400Vrange,forexample,themajordivisionsonthescalerepresent0V,100V,200V,300Vand400V.An
inputof-100Vlightsthenegativesignandthesegmentsuptothe«10»onthescale.
GENERAL SPECIFICATION
Maximum Voltage between any Terminal and Earth Ground: 600V DC or AC rms
Fuse Protection for "A°C°F" Terminal Inputs:400mA,690V,FAST,Min.InterruptRating20000A
Display: 3 3r4-digit LCD, with a max. reading of 3999
Overrange Indication:"OL"shownontheLCD
Negative Polarity Indication: " " displayed on the LCD automatically
Sampling Rate: about 2-3 times/sec
Operating Temperature: 0° C - 40° C, < 75% RH
Storage Temperature: -20° C - 60° C,< 85% RH
Operating Altitude: 0 to 2000 meters
Battery: 1.5V battery, AA or equivalent, 6 pieces
Low Battery Indication: " " shown on the display
Dimensions:202X117X65mm
Weight: about 705g (including batteries)
mV, V
ɥA, mA, A
mΩ, Ω, kΩ, MΩ
Hz, kHz, MHz
RPM
°C, °F
°
%
13
14
15
16
17
