DIGITAL DISPLAY

complete list of messages.
LANGUAGE/CHARGER AND POWER SUPPLY BUTTON
LANGUAGE: 
the button for 5 seconds to select the language on the display.
(EN FR ES IT).
CHARGER AND POWER SUPPLY: Click the button to select mode (charger or power supply),
then double click the button to enter the mode which you selected.
LED INDICATOR
The charger is connected and is charging a battery.
The battery is fully charged and the charger
is in Maintain Mode.
The charge has aborted. (See Aborted Charge section.)
NOTE: See Operating Instructions for a complete description of the charger modes.

This battery charger must be properly assembled in accordance with the
assembly instructions before it is used.
The charger does not have an ON/OFF switch. The On and Off commands are controlled by
plugging the BC1215 into an AC electrical wall outlet only after the battery connections have
been made.

damage the charger and your vehicle.
BATTERY INFORMATION

NOTE: This charger is equipped with an auto-start feature. Current will not be supplied to
the battery clamps until a battery is properly connected. The clamps will not spark if touched
together.


CHARGING
1. Ensure that all of the charger components are in place and in good working condition.
2. Connect the battery, following the precautions listed in sections 6 and 7.
3. Connect the AC power following the precautions listed in section 8.
4. When the charger starts, the GREEN LED will be solid, and the display will show
ANALYZING BATTERY while the charger determines that the battery is properly
connected and the condition of the battery.
5. When the battery is fully charged, the GREEN LED will pulse.
6. When charging is complete, disconnect the AC cord from the supply mains, remove the
clamp from the vehicle’s chassis, and then remove the clamp from the battery terminal.
POWER SUPPLY
1. Ensure that all of the charger components are in place and in good working condition.
2. Connect the battery, following the precautions listed in sections 6 and 7.
3. Connect the AC power following the precautions listed in section 8.
4. When the power supply starts, the GREEN LED will be solid, and the display will show
POWER SUPPLY ON.
10. CONTROL PANEL
11. OPERATING INSTRUCTIONS
WARNING
IMPORTANT
