Apply Loctite 243 on bolt threads. Thread the bolt in but do not
tighten, this will allow the insert to align when installing the
axle
Remove the thru-axle and remove the hub. Install front wheel
and tighten the thru axle (with the nylon washer) to 12Nm.
Install a front hub in the dropout with the free hub
on non-drive side. This will allow better access for
the next step. Install the thru-axle with the nylon
washer and tighten to 12Nm
After ensuring the dropout insert is correctly
aligned, tighten the dropout bolt to 1 Nm.
7-1
7-4
7-2 7-3
Fork nut adjustment
rotor-mount
on drive side !
