Assembly Manual 01
Necessary tools
Instructions
1-1
Torque wrench with 2.5, 3, 4, 5mm hex & Torx T20 bits
BRT-002 bearing press from Enduro Bearings
Sand paper (120-180 grit)
Park Tool IR-1
Grease & Loctite 243 & 641
Isopropyl alcohol
Seatpost 1-2 1-3
Adjust the set back and saddle angle to the desired position.
Tighten the M6 saddle clamp bolt to 12 Nm.
round 7x7mm rails
oval 7x9mm rails
Insert battery in the seat post.
Similar to a Formula 1 car your Factor ONE requires a bit of patience and mechanical skill to achieve a truly impressive result.
We recommend that you have your bicycle assembled and maintained by an authorized Factor dealer. Make sure to let your
mechanic know how much you appreciate their help building the bike of your dreams!
Place the battery holders around
the Di2 battery. The male shell
grooves must match with the
female battery groove.
